Double sided PVC tape is using white PVC film as backing material and coated with solvent acrylic adhesive. It is suitable for fixing model / decorative objects in furniture industry, as well as fixing load components in electric industry.
Share
Details of Double Sided PVC Tape
Liner: Yellow glassine paper liner
Adhesive: Solvent acrylic
Adhesive color: Transparent
Size: 1240mm x 100m (Jumbo roll size)
1240mm x 50m or customized (Log roll size)
50mm x 25/50m or customized (Cut roll size)
Features:
* Good toughness & Easy to tear
* Good electric flammability and soft property
* High mechanical pressure resistance
* Strong adhesive force and the holding capacity
* Not influenced by most chemical substances and humidity
* Irregular surface application for its great conformability
Technical Data of Double Sided PVC Tape
| Part No. | DVT68G |
| Total thickness | 400±5mic |
| Tape thickness | 325±5mic |
| Liner thickness | 75±5mic |
| Adhesive to steel | 20N/25mm |
| Holding power | ≥ 24hrs/1000g/6.4cm2 |
| Initial tack | ≤ 100mm |
| Color | White |
| Solvent resistance | Good |
| Temp resistance | 60℃ |
| Part No. | DVT70G |
| Total thickness | 300±5mic |
| Tape thickness | 225±5mic |
| Liner thickness | 75±5mic |
| Adhesive to steel | 18N/25mm |
| Holding power | ≥ 24hrs/1000g/6.4cm2 |
| Initial tack | ≤ 100mm |
| Color | White |
| Solvent resistance | Good |
| Temp resistance | 60℃ |
Applications of Double Sided PVC Tape
Double sided PVC tape is suitable for fixing model / decorative objects in furniture industry, as well as fixing load components in electric industry.
